EJYWPSWD GRT8-2T Double Delay on Timer Relay AC230V OR AC/DC12V-240V DPDT Din Rail Type Time Delay Relay

<p>Applications</p><p>-For gradual switching of heavy powers (e.g. el.heating), prevents currentstrokes in the main.</p><p>Function Features</p><p>- GRT8-2T 2x Delay ON (2 time relays in one)</p><p>-Time scale 0.1s - 10 days divided into10 time ranges:</p><p>0.1s - 1s / 1s - 10s / 0.1min - 1min / 1min - 10min / 0.1h - 1h / 1h - 10hrs/ 0.1 day - 1 day / 1 day - 10 days / ON / OFF.</p><p>- Times t1 and t2 are independantly adjustable.</p><p>- t1 and t2 are switched on after supply voltage connection</p><p>- Output: 2SPDT 16A/AC1</p><p>- Voltage Range: AC230V or AC/DC12-240V</p><p>- Relay status is indicated by LED.</p><p>- 1-MODULE,DIN rail mounting</p><p>Power Source : AC</p><p>Theory : Time Relay</p><p>Contact Load : Low Power</p><p>Model Number : GRT8-2T Double Delay on Timer</p><p>Voltage : 24V</p><p>Use : General Purpose</p><p>Protect Feature : Sealed</p><p>Product Name : GRT8-2T Double Delay on Time Relay</p><p>Function : Delay on Time Relay</p><p>Voltage : AC230V OR AC/DC12-240V</p><p>Output Contact : 2SPDT/DPDT</p><p>Rated Current : 16A</p><p>Time Range : 0.1s-10days (in 10 time range)</p>
